Infiniti QX: Meters and gauges
1. Tachometer
2. Warning/Indicator lights
3. Speedometer
4. Engine coolant temperature gauge
5. Voltmeter
6. Dot matrix liquid crystal display/
Odometer/twin trip odometer
7. Engine oil pressure gauge
8. Fuel gauge
: The needle indicators may move slightly
after the ignition switch is pushed to the
OFF position. This is not a malfunction.
- Speedometer and odometer
- Tachometer
- Engine coolant temperature gauge
- Fuel gauge
- Engine oil pressure gauge
- Voltmeter
- Meter/ring illumination and needle sweep
Instrument panel
1. Side ventilator
2. Meters and gauges
3. Hazard indicator flasher switch
4. Center ventilator
5. Center multi-function control panel
— Vehicle information and setting
buttons
6. Ce ...
Speedometer and odometer
Speedometer
Speedometer
The speedometer indicates vehicle speed
in miles per hour (MPH) and kilometers per
hour (km/h).
Odometer/twin trip odometer
Odometer/twin trip odometer
The o ...
