Buick Enclave: Where Are the Airbags?
The driver frontal airbag is in the center of the steering wheel.
The front outboard passenger frontal airbag is in the passenger side instrument panel.
Driver Side Shown, Passenger Side Similar
The driver and front outboard passenger seat-mounted side impact airbags are in the side of the seatbacks closest to the door.
Driver Side Shown, Passenger Side Similar
The roof-rail airbags for the driver, front outboard passenger, and second and third row outboard passengers are in the ceiling above the side windows.
WARNING
If something is between an occupant and an airbag, the airbag might not inflate
properly or it might force the object into that person causing severe injury or
even death. The path of an inflating airbag must be kept clear. Do not put anything
between an occupant and an airbag, and do not attach or put anything on the steering
wheel hub or on or near any other airbag covering.
Do not use seat accessories that block the inflation path of a seat-mounted side impact airbag.
Never secure anything to the roof of a vehicle with roof-rail airbags by routing a rope or tie-down through any door or window opening. If you do, the path of an inflating roof-rail airbag will be blocked.
Airbag System
The vehicle has the following airbags:
► A frontal airbag for the driver.
► A frontal airbag for the front outboard passenger.
► A seat-mounted side impact airbag for the driver.
...
When Should an Airbag Inflate?
Frontal airbags are designed to inflate in moderate to severe frontal or near
frontal crashes to help reduce the potential for severe injuries, mainly to the
driver's or front outboard passeng ...
See also:
When Should an Airbag Inflate?
Frontal airbags are designed to inflate in moderate to severe frontal or near
frontal crashes to help reduce the potential for severe injuries, mainly to the
driver's or front outboard passeng ...
Engine Compartment Overview
6.2L V8 Engine
A. Engine Air Cleaner/Filter .
B. Coolant Surge Tank and Pressure Cap. See Cooling System .
C. Remote Positive (+) Terminal. See Jump Starting .
D. Battery ...
Antenna
Window antenna
The antenna pattern is printed inside the
3rd row seat window.
CAUTION
► Do not place metalized film near the 3rd
row seat window or attach any metal
parts to it. This ...
