Introduction

When the automatic transmission is in position D, it is possible to restrict or derestrict the shift range.

The shift range selected is shown in the multifunction display. The automatic transmission shifts only as far as the selected gear.

Restricting the shift range

Restricting the shift range

Pull the left-hand steering wheel paddle shifter.

The automatic transmission shifts down one gear and restricts the shift range to the relevant gear.

engine speed when shifting down, the If the engine exceeds the maximum engine speed when shifting down, the automatic transmission protects against engine damage by not shifting down.

range is reached and you continue to If the maximum engine speed for the shift range is reached and you continue to accelerate, the automatic transmission shifts up in order to prevent the engine from overrevving, even if the shift range is restricted.

Derestricting the shift range

Pull the right-hand steering wheel paddle shifter.

The shift range is derestricted.

Clearing the shift range restriction

Pull and hold the right-hand steering wheel paddle shifter until D is shown again in the multifunction display.

The automatic transmission shifts from the current shift range directly to D.

Selecting the ideal shift range

Pull the left-hand steering wheel paddle shifter and hold it in position.

The automatic transmission shifts to the gear which allows optimum acceleration and deceleration. To do this, the automatic transmission shifts down one or more gears.

    Steering wheel paddle shifters
    1 Left-hand steering wheel paddle shifter 2 Right-hand steering wheel paddle shifter You can restrict or derestrict the shift range by using the steering wheel paddle shifters. ...
