Cadillac Escalade: Instrument Panel Fuse Block - Electrical System - Vehicle Care - Cadillac Escalade Owner's ManualCadillac Escalade: Instrument Panel Fuse Block

The instrument panel fuse block access door is located on the driver side edge

The instrument panel fuse block access door is located on the driver side edge of the instrument panel.

Pull off the cover to access the fuse block.

The vehicle may not be equipped with all of the fuses, relays, and features shown.

The vehicle may not be equipped with all of the fuses, relays, and features shown.
