Mercedes-Benz GL-Class: Cockpit - At a glance - Mercedes-Benz GL-Class Owner's ManualMercedes-Benz GL-Class: Cockpit

1 Combination switch

1 Combination switch
2 Cruise control lever
3 Instrument cluster
4 Horn
5 Steering wheel paddle shifters
6 DIRECT SELECT lever
7 PARKTRONIC warning display
8 Overhead control panel
9 Climate control systems
10 Ignition lock Start/Stop button
11 Adjusts the steering wheel manually
12 On-board diagnostics socket
13 Opens the hood
14 Parking brake
15 Releases the parking brake
16 Light switch
17 Adjusts the steering wheel electrically
Steering wheel heating
